Motion activated SMS Shield- Tutorial

Motion activated SMS Shield- Tutorial

Send an SMS every time something moves in your room

  • 4,234 views
  • 2 comments
  • 5 respects

Components and supplies

About this project

http://www.youtube.com/watch?v=zj44N8mDYm0
Warning: embedding parts within the project story has been deprecated. To edit, remove or add more parts, go to the "Hardware" tab. To remove this list from the story, click on it to trigger the context menu, then click the trash can button (this won't delete it from the "Hardware" tab).
A000066 iso both
Arduino UNO & Genuino UNO
Comment
Screen shot 2019 03 20 at 2 38 27 pm fqndazqcx1
1Sheeld
Comment
13285 01
PIR Motion Sensor (generic)
Comment
12002 04
Breadboard (generic)
Comment
09590 01
LED (generic)
Comment
11026 02
Jumper wires (generic)
Comment
Untitled file

Warning: Embedding code files within the project story has been deprecated. To edit this file or add more files, go to the "Software" tab. To remove this file from the story, click on it to trigger the context menu, then click the trash can button (this won't delete it from the "Software" tab).

//1sheeld.com for the steps on adding the libraries to your arduino program

#include <OneSheeld.h>
int ledPin = 13;                // choose the pin for the LED
int inputPin = 2;               // choose the input pin (for PIR sensor)
int PIR = LOW;
int val = 0;

void setup() {
  pinMode(ledPin, OUTPUT);      // declare LED as output
  pinMode(inputPin, INPUT);     // declare sensor as input
   OneSheeld.begin();
}

void loop(){
  val = digitalRead(inputPin);  // read input value
  if (val == HIGH) {            // check if the input is HIGH
    digitalWrite(ledPin, HIGH);  // turn LED ON
    delay(150);

    if (PIR == LOW) {
       SMS.send("0123456789","Motion DETECTED");  // change number with your own here
       PIR = HIGH;
    }
  } else {
    digitalWrite(ledPin, LOW); // turn LED OFF

    if (PIR== HIGH){
      PIR = LOW;
    }
  }
}


Code

file_7669.txtC/C++
//1sheeld.com for the steps on adding the libraries to your arduino program

#include <OneSheeld.h>
int ledPin = 13;                // choose the pin for the LED
int inputPin = 2;               // choose the input pin (for PIR sensor)
int PIR = LOW;
int val = 0;

void setup() {
  pinMode(ledPin, OUTPUT);      // declare LED as output
  pinMode(inputPin, INPUT);     // declare sensor as input
   OneSheeld.begin();
}

void loop(){
  val = digitalRead(inputPin);  // read input value
  if (val == HIGH) {            // check if the input is HIGH
    digitalWrite(ledPin, HIGH);  // turn LED ON
    delay(150);

    if (PIR == LOW) {
       SMS.send("0123456789","Motion DETECTED");  // change number with your own here
       PIR = HIGH;
    }
  } else {
    digitalWrite(ledPin, LOW); // turn LED OFF

    if (PIR== HIGH){
      PIR = LOW;
    }
  }
}
