Project tutorial

Ultrasonic Sensor with LCD Display Using 433MHz
Display the results from the HC-SR04 ultrasonic sensor on an LCD display using 433MHz transmitter and receiver.
- 19,921 views
- 1 comment
- 29 respects
Components and supplies
About this project
In this project, I will show you how make two Arduinos talk to each other using RF frequency (wireless). Now I will show you in all these project and improve on them by making one Arduino send data to another Arduino wirelessly using an RF433 module and displaying it on I2C serial LCD.
Code
#include <VirtualWire.h> //Load the library
const int trigPin = A0;
const int echoPin = A1;
float duration, distance;
char msg[6];
void setup()
{
vw_set_tx_pin(12); // Sets pin D12 as the TX pin
vw_setup(2000); // Bits per sec
pinMode(trigPin, OUTPUT);
pinMode(echoPin, INPUT);
Serial.begin(9600);
}
void loop()
{
digitalWrite(trigPin, LOW);
delay(500);
digitalWrite(trigPin, HIGH);
delay(500);
digitalWrite(trigPin, LOW);
duration = pulseIn(echoPin, HIGH);
distance = (duration*.0343)/2;
Serial.print("Distance: ");
Serial.println(distance);
dtostrf(distance, 6,2,msg); //converts the float into a char
vw_send((uint8_t *)msg, strlen(msg)); //transmits the data
vw_wait_tx(); // Wait until the whole message is gone
delay(500);
}
I will connect the NANO with the LCD and the RF433-RX module
Plug in the NANO on the breadboard
Then insert the RF433-RX module
Connect the VCC and the GND from the RF433-RX to the NANO GND and VCC and connect the Data PIN (left most pin) to the digital pin 12 on the NANO
Connect the GND and the VCC from the I2C serial LCD to the GND and the VCC pins on the NANO, then connect the SDA to analog pin 4 on the NANO and the SCL to analog pin 5 on the NANO.
Plug in the NANO on the breadboard
Then insert the RF433-RX module
Connect the VCC and the GND from the RF433-RX to the NANO GND and VCC and connect the Data PIN (left most pin) to the digital pin 12 on the NANO
Connect the GND and the VCC from the I2C serial LCD to the GND and the VCC pins on the NANO, then connect the SDA to analog pin 4 on the NANO and the SCL to analog pin 5 on the NANO.
//load libraries
#include <VirtualWire.h>
#include <Wire.h>
#include <LCD.h>
#include <LiquidCrystal_I2C.h>
//Define variables
#define I2C_ADDR 0x3F //Define I2C Address where the PCF8574A is
#define BACKLIGHT_PIN 3
#define En_pin 2
#define Rw_pin 1
#define Rs_pin 0
#define D4_pin 4
#define D5_pin 5
#define D6_pin 6
#define D7_pin 7
//Initialise the LCD
LiquidCrystal_I2C lcd(I2C_ADDR, En_pin,Rw_pin,Rs_pin,D4_pin,D5_pin,D6_pin,D7_pin);
int i; //and integer used to count
void setup()
{
//Define the LCD as 16 column by 2 rows
lcd.begin (16,2);
//Switch on the backlight
lcd.setBacklightPin(BACKLIGHT_PIN,POSITIVE);
lcd.setBacklight(HIGH);
//Define the receiver pin and rate
vw_set_rx_pin(12); //Sets pin D12 as the RX Pin
vw_setup(2000); // Bits per sec
vw_rx_start(); // Start the receiver PLL running
}
void loop()
{
uint8_t buf[VW_MAX_MESSAGE_LEN];
uint8_t buflen = VW_MAX_MESSAGE_LEN;
if( vw_get_message(buf, &buflen) )
{
lcd.setCursor(0, 0);
lcd.print("distance is:");
lcd.setCursor(3,1);
for (i = 0; i < buflen; i++)
{
lcd.write(buf[i]);
}
lcd.print((char)223);
}
}
Schematics
Comments
Author
Published on
July 28, 2018Members who respect this project
you might like
First connect the GND and the VCC from the Arduino to the bread board
Insert the LM35 on the breadboard and connect the GND and the VCC.
Insert the RF433-TX module, place it facing you and Pins should be DATA, VCC, GND from left to right
Connect the VCC and the GND to the +/- rails on the breadboard and the Data pin connects on digital pin 12 on the Arduino.
